Bitzer chiller Room Refrigeration Condensing Units

Refrigeration Compressor Condensing Unit For Chiller

"Meluck"  remote refrigeration systems are composed of a condensing unit with matching evaporator coil. With remote systems, the condensing unit is located away from a walk in cooler or freezer, usually outside a building or on a roof, while the evaporator coil is inside the walk in.

Use a walk-in freezer condensing unit to keep your storage box at the perfect temperature



Inquiry Now

Parameter:

Descriptions

1.Product Description

According to demands of market, we design XJ series. This series products feature box type structure with Bitzer Semi-hermetic compressor
and control box, The applicable temperature ranges are: -5℃~5℃ and -15~-30℃. They can be widely used pre-cooling Room,chiller room,
freezer room, quick freezing room.
◆ Use durable running orginal Bitzer semi-hermetic compressor
Copper tube-Aluminum/Nanolayer fin is optiona for Coastal area.
◆ With multi protections including phase protection, phase lack, over current, too constant start of compressor, discharge
temp and system high/low temp.
◆ With fan speed regulator, to adjust condensing fan according to condensing temp.
◆ With operation data display function, to check operation current of compressor, discharge temp. and condensing temp.
◆ With system alarm function. When fault effects, the system will make alarm beep sound to remind user.
◆ The operation board can be installed apart for remote control.

3.Parameters

Main components:

①compressor②oil heating belt ③Vibration Eliminator ④ Oil Separator ⑤condenser ⑥liquid receiver ⑦ filter ⑧ sight glass

⑨solenoid valve ⑩H/L pressure gaugemechanical pressure switchOil pressure protectionoil/liquid accumulator

Lowpressure control (for compressor)○15Electrical control



4.Product Display
